| Material specification: | Aluminium Barrel 99.6%, Copper Palm : 99.95% |
|---|---|
| Final Metal State : | Fully Annealed, Including Joint. |
| Joining Method : | Friction Welding, Welding Area more than Nominal Conductor Area. |
| Finish: | Natural |
Conductivity : Aluminium 61.8% IACS (Min) Copper 99.7% IACS Aluminium Barrel are Chemically treated to reduce contact resistance and corrosion and are filled electrically conductive corrosion inhabitant with a jointing compound and capped. Note : 1. Combinations of BI-Metalic Compression Joints are designed on the basis of current carrying capacity of individual cables. 2. In case additional combinations are required same may will be provided against specific request.
